Standard Features
-Hydraulic 3-Jaw Chuck
-8-Station Turret
-Full Guard
-Work Light
-Tri-color alarm light
-Automatic Lubrication System
-Automatic Coolant System
Optional Features
-Different Chucks and Collets
-Different Control System
-Different Spindle Speed and Bore Dia
-Chip Conveyor
-Bar Feeder
-Gang Type Tool Holders
| Specifications | Unit | GT260V | GT260V-650 | |||
| Capacity | Chuck/collet | inch | 8" | 8" | ||
| Max. swing dia. over bed | mm | Φ580 | Φ580 | |||
| Max. length of work piece | mm | 340 | 650 | |||
| Max. swing dia. over slide | mm/min | Φ200 | Φ200 | |||
| Spindle | Spindle bore | mm | Φ62 | *Φ75 | Φ62 | *Φ75 |
| Max. dia. of through hole | mm | Φ52 | *Φ65 | Φ52 | *Φ65 | |
| Spindle nose | type | A2-6 | *A2-8 | A2-6 | *A2-8 | |
| Spindle speed | rpm | 4000 | *3500 | 4000 | *3500 | |
| Main motor power | kW | 11/15 | 11/15 | |||
| Axis | X1 Axis Travel | mm | 160 | 160 | ||
| Z1 Axis Travel | mm | 340 | 650 | |||
| X2 Axis Travel | mm | 160 | 160 | |||
| Z2 Axis Traver | mm | 340 | 650 | |||
| X1/Z1 Rapid Traverse | m/min | 25 | 20 | |||
| X2/Z2 Rapid Traverse | m/min | 25 | 20 | |||
| Turret | Turret 1 stations | 8 | 8 | |||
| Turret 2 stations | 8 | 8 | ||||
| OD Tool Shank size | mm | 25*25 | 25*25 | |||
| Boring Bar size | mm | Φ40 | Φ40 | |||
| Tailstock | Type of tailstock | N/A | SST | |||
| Taper of tailstock quill | N/A | MT4 (Spindle unit type) | ||||
| Travel of tailstock | mm | N/A | 550 | |||
| Others | Slant Bed Degree | 90° | 90° | |||
| Guideway Type | Linear Motion Guideway | Linear Motion Guideway | ||||
| Power Capacity | kVA | 20 | 25 | |||
| Overall Dimension (L*W*H) | mm | 2850*1850*2300 | 3300*1850*2350 | |||
| Weight (About) | kg | 7000 | 9000 | |||
