-8" chuck size
-12 stations
-22.0/30.0 kW
-Two spindle turning center
-Heavy duty linear guide ways on X, Y, Z and E axes
-Automatic docking combined with Y axis, C axis and power driven turret makes integrity solution
-Power driven turret mounted on Y Axis at the angle 45°
-Smilutaneous part docking can be realized between main spindle and sub spindle
| Specification | |
| Capacity | Max. Swing Diameter Over Bed : Ø460mm |
| Max. Turning Diameter: Ø320mm | |
| Max. Length of workpiece: 400mm | |
| Max. Swing Dia. Over Slide: Ø400mm | |
| Spindle | Main Spindle Speed: 4000rpm |
| Main main motor: 22.0/30.0kW | |
| Main Spindle nose: A2-6 | |
| Main Spindle Chuck size: 8" | |
| Main Spindle Bore: Ø66mm | |
| Main Spindle Drawbar Capacity: Ø52mm | |
| Sub Spindle Speed: 5000rpm | |
| Main main motor: 11.0/15.0kW | |
| Sub Spindle nose: A2-5 | |
| Sub Spindle Chuck size: 6" | |
| Sub Spindle Bore: Ø55mm | |
| Main Sppindle Drawbar Capacity: Ø46mm | |
| Axis | X/ Y/ Z/ B Axis Travel: 180mm/ 100(卤50)mm/ 400mm/ 400mm |
| X/ Z1/ Z2/ Y Rapid traverse: 18/ 30/ 30/ 10 m/min | |
| Tools | Type: BMT55 |
| Number of Tool Stations: 12 | |
| OD Tool shank size: 25×25mm/Boring tool shank size: ∅40mm | |
| live Tooling Motor: 3.7kW/ 5.5kW | |
| Max. Speed of Live Tooling: 5000rpm | |
| Tailstock | Type of tailstock:Servo programmable |
| Taper of tailstock quill:MT5 | |
| Travel of tailstock:80-400mm | |
